5000 LPH RO Plant

 726,100

5000 LPH RO Plant with elegant and superior design and the use of Reverse Osmosis Technology With Open Type Model, Stainless Steel body. Fully automatic panel board equipped with Five membrane and Two membrane housing. This Industrial RO Plant is capable of removing pollutants and impurities from the raw water and filters purified and safe water for drinking purpose

Check Availability At //

Special Features of 5000 LPH RO Plant  :

  • Designed as Energy efficient so very less power consumption. Since we use the best quality electrical components and pumps.
  • Environment friendly model because of low wastage.
  • The plant is designed according to the Standards and requirements of a particular industry or business
  • 5000 LPH RO Plant SS provides high output and a long life span
  • Non-Corrosive: The skid provides with this 5000LPH RO system is made up of stainless steel. So the product is corrosion free.

Advantages of 5000 LPH RO Plant  :

  • Ideal for Schools, College, Hospitals, Factories, Restaurants, Hotels and other Educational Institutions.
  • Can also be used for Industrial and business purposes like corporate offices, Manufacturing plants, Pharmaceutical purposes, commercial buildings and malls etc.
  • 100% pure, healthy and safe water for your consumption.
  • Purify any type of water like Underground water or Supply water.
  • Durable product and requires very less maintenance

Specification 5000 LPH RO

MODEL 5000 LPH SS CLASSIC AUTO
PUMP CRI MVC- 10/20TR (10 HP) – III PHASE
MEMBRANE FILMTEC BW 30 -8040 MEMBRANE (5 NOS)
PANEL ASTERO
PANEL MODEL RO ASTERO (3-3)
INPUT VOLTAGE 430 VOLT AC(50Hz)
MEMBRANE HOUSING 80120 – 1 NO & 8080 – 1NO (UKL MAKE
FILTER HOUSING UPVC 30″ X 5 (1NO)
FILTER 5 NOS 30″ X 2.5″WOUND
VESSEL            3072 FRB – 3072 FRB -2NOS ( TATA )
4″ DISTRIBUTION SET 2 NOS
HUB & LATERAL 175MM -2NOS,
MULTIPORT VALVE 50 NB- SFV- 2 NOS (UKL MAKE)
PEBBLES 11BAG
SILEX 12 BAG
CARBON 150 KG
LPS 1 NO (BAUMER)
HPS 1 NO (BAUMER)
PRESSURE GUAGE 3 NOS
FLOW METER 2 NOS (UKL)
FLOAT 1 NO
PIPE LINE UPVC/CPVC
SKID SS
SKID DIMENSION 60″ (H) x 84″ (W) x 28″ (L)
RAW WATER PUMP 5.0HP- 1NO
DOSING PUMP ( UKL/ E DOSE/ I DOSE )
ANTISCALANT 50 kG
TECHNOLOGY REVERSE OSMOSIS SYSTEM
APPLICATION SUITABLE FOR PURIFICATION OF BRACKISH WATER
Country of Origin INDIA
